Scissor Lift
Scissor Lift
A serious piece of kit and extremely versatile with several different platform lengths and load capacities
A serious piece of kit and extremely versatile with several different platform lengths and load capacities
Crypton’s Scissor lift is a serious piece of kit and extremely versatile
with several different platform lengths and load capacities for class 4 and class 7 vehicles.
Its compact design and absence of posts offer a completely obstruction-free solution for workshops looking to maximise available space. Also, it's popular quality checker plate surface is extremely attractive, whilst providing maximum protection against corrosion for a long-term investment.
The scissor lift is supplied with a brake pedal depressor & turntables as standard, as well as wirelessly-operated play detectors for flexibility & a safer working environment. The jacking beam rail is positioned underneath the platform to remain debris-free, allowing it to run smoothly with very little maintenance. The two independent hydraulic systems guarantee a quiet, powerful and reliable synchronisation & the ability to safely lock at your desired height.
Its compact design and absence of posts offer a completely obstruction-free solution for workshops looking to maximise available space. Also, it's popular quality checker plate surface is extremely attractive, whilst providing maximum protection against corrosion for a long-term investment.
The scissor lift is supplied with a brake pedal depressor & turntables as standard, as well as wirelessly-operated play detectors for flexibility & a safer working environment. The jacking beam rail is positioned underneath the platform to remain debris-free, allowing it to run smoothly with very little maintenance. The two independent hydraulic systems guarantee a quiet, powerful and reliable synchronisation & the ability to safely lock at your desired height.
| Specification | Class 4 CTL843/844 | Class 7 CTL870/871 |
|---|---|---|
| Standard in ground | ||
| Lifting capacity | 4000kg | 4000kg |
| Lifting | 1,770mm (approx) | 1,930mm (approx) |
| Lowering time | 20 sec (approx) | 38 sec (approx) |
| Runway | 600mm | 635mm |
| Runway length | 4540mm | 5460mm |
| Total width | 2,150mm (Pit) | 3230mm |
| Motor | 3.0kW | 3.0kW |
| Power supply | 400/50 V/Hz | 400/50 V/Hz |
| Supply fuse | T16A | T16A |
