Midrise Scissor Lift

Midrise Scissor Lift

An efficient, reliable and versatile solution

Crypton's midrise scissor lift is an efficient, reliable and versatile solution. With its fast lifting times, robust steel construction and high-quality hydraulic system, it lifts most vehicles, including low sports cars to heavy SUV’s up to 3 tonnes. Its one metre lifting height makes it comfortable for tyre, brake, suspension, paint and other bodywork tasks.

Its compact design and mobile ability allows the lift to fit in any workshop and can be placed just about anywhere without getting in the way. Thanks to its solid steel construction and anti-skid platform, it can even be used outdoors, creating additional work space in no time.

Assembled at the factory for quick plug and play installation.
  • Features

    ✓ Extended platforms for long wheel-base vehicles

    ✓ Attractive checker plate surface

    ✓ Anti-skid platform

    ✓ Front and rear mounting ramps

    ✓ Hydraulically operated

    ✓ Red rubber anti-toe traps

    ✓ Supplied with four ductile polymer pads to protect the vehicle’s under-body

    ✓ Portable control unit

  • Additional Information
    • Includes 4 ductile blocks to protect the vehicle's underbody
    • Hydraulic oil not included
  • Brochures and Manuals

    Download Midrise Scissor Lift Flyer

    Download Midrise Scissor Lift Manual

  • Product Warranty

    We are pleased to supply and install with 3 years warranty (UK mainland only)

Specification CML3000
Lifting capacity 3000kg
Lifting height 990mm
Lowest lifting point 102mm
Drive over height 102mm
Overall height 990mm
Overall width 1,900mm
Runaway width 450mm
Runaway Length 1,400 - 2,010mm
Power supply Single phase
Motor 1,5kW
Motor Speed 3,000 rpm
Hose Length 3m
Hydraulic pressure 230bar
Pressure relief valve 260bar
Oil tank 8 Litres
Sound level ≤70dB
Connection by customer Fuse 16amp (motor rated trip)
